Introduction

I tested five current local vision-language models on one NVIDIA RTX 4090 across Ollama and direct llama.cpp, centered on Qwen3.8-27B and Gemma4-26B. The work covered installation, model downloads, coding-harness configuration, practical text and vision context ceilings, multi-token prediction (MTP), short and filled-context throughput, CPU offload, matched runtime performance, and 360 W versus 450 W GPU power limits.

Two models emerged as the most useful daily pair:

  • Use Gemma4-26B for the fastest generation and longest practical full-GPU context.
  • Use Qwen3.8-27B for difficult coding, agents, reasoning, and more reliable visual interpretation.
  • Use Ollama for normal daily operation; use direct llama.cpp when exact GGUF, K/V precision, MTP, projector, or benchmarking control matters.

The complete setup and all five-model results are retained below so the conclusions remain reproducible.

RTX 4090 Test Hardware

All results in this guide were measured on this machine. Unless a table says otherwise, the RTX 4090 was limited to 360 W.

ComponentHardware
OSUbuntu 26.04 LTS, Linux 7.0.0-28-generic
CPUAMD Ryzen 9 3900X, 12 physical cores / 24 threads
RAM32 GB installed (free -h reports 31 GiB)
GPUNVIDIA GeForce RTX 4090, 24,564 MiB VRAM
GPU power360 W tested; NVIDIA default 450 W; board maximum 600 W
NVIDIA driver595.84
Model/data root~/dev/ml-data

The 24 GB GPU is the main constraint. Full GPU residency is fast; partial CPU offload can cause a severe decode-speed cliff, as Gemma4-31B demonstrates in the Ollama 65K benchmark.

Five Local Models Tested

These five models are retained in both runtimes and sorted by name. The reported context is the model’s architectural window, not a promise that the model, projector, MTP state, and KV cache fit in 24 GB VRAM at that size.

ModelParametersTypeReported contextCapabilitiesOllama packagellama.cpp package
gemma4:26b25.2B, about 3.8B activeMoE262,144text, vision, tools, thinkingQ4_K_MUnsloth UD-Q4_K_XL
gemma4:31b30.7Bdense262,144text, vision, tools, thinkingQ4_K_MUnsloth UD-Q4_K_XL
qwen3.6:27b27Bdense262,144text, vision, tools, thinkingQ4_K_MUnsloth UD-Q4_K_XL
qwen3.6:35b35B, about 3B activeMoE262,144text, vision, tools, thinkingQ4_K_MUnsloth UD-Q4_K_XL
qwen3.8:27b27Bdense262,144text, vision, tools, thinkingQ4_K_MUnsloth UD-Q4_K_XL

Model type, parameter counts, context, and capabilities were checked against the current Unsloth model cards/guides and the corresponding Ollama package metadata. The actual llama.cpp request ceilings are measured later in this guide.

Recommendation — Two base models are enough: Use gemma4:26b for fast, long-context work and qwen3.8:27b for the highest-quality dense local model. Keep the other three models only as benchmark references or for targeted experiments.

RoleModelWhy
Fast / long contextgemma4:26bMoE with about 3.8B active parameters; 182.7 t/s at 65K in the local Ollama benchmark.
Quality / difficult coding and agentsqwen3.8:27bStronger official coding and agent results than Qwen3.6; 90.9 t/s at 65K with stock Ollama MTP 4.

Only these two base downloads are required for normal use:

ollama pull gemma4:26b
ollama pull qwen3.8:27b

Context and Vision

The same base tag handles both text and images. Vision does not require another weight download or a special vision tag: both packages already include their multimodal support. Most daily use is through a coding harness, so use fixed aliases rather than relying on a harness to send Ollama-native request options.

Filled requests established the useful full-GPU boundary and the first CPU-offloaded point. Vision used the fixed real image, not merely a loaded projector.

ModelText: max 100% GPUText: first offloadVision: max 100% GPUVision: first offload
gemma4:26b196,608229,376 (92% GPU)196,608229,376 (92% GPU)
qwen3.8:27b65,53698,304 (81% GPU)65,53698,304 (81% GPU)

“100% GPU” means the model and allocated KV cache are fully GPU-resident, not that the context is always full or that tokens/s is maximal. Gemma also completed 262,144-token text and vision requests at 89% GPU, but those are academic capacity results: CPU offload is slower, so use 196K. Qwen’s offload penalty is much steeper, so use 65K in Ollama; direct llama.cpp reaches a larger useful window with q8 K/V.

Set num_ctx explicitly. Current Ollama chooses only 4K below 24 GiB VRAM, 32K from 24-48 GiB, and 256K at 48 GiB or more. The RTX 4090 reports 24,564 MiB—approximately 23.99 GiB—so it sits directly on the lower threshold and should not rely on automatic context selection.

For an image through the CLI, use the same model name:

ollama run qwen3.8:27b ./image.png "Describe this image accurately."
ollama run gemma4:26b ./image.png "Describe this image accurately."

The native /api/chat API accepts base64 image data in messages[].images and accepts num_ctx under options. The OpenAI-compatible API used by OpenCode and Pi supports vision and tools but has no per-request context-size field, so its model name must point to an alias with the intended num_ctx. See Configure Context and MTP for native API diagnostics and service-wide configuration.

Harness-Safe Ollama Profiles

Create these once. They inherit the base blobs and do not download the weights again.

# Modelfile.gemma26
FROM gemma4:26b
PARAMETER num_ctx 196608
# Modelfile.qwen38
FROM qwen3.8:27b
PARAMETER num_ctx 65536
PARAMETER draft_num_predict 4
ollama create gemma4-26b-196k -f Modelfile.gemma26
ollama create qwen3.8-27b-65k -f Modelfile.qwen38

Each alias supports both text and images, so only two profiles are needed. They reuse the base blobs instead of downloading weights again. Do not add draft_num_predict to Gemma: its stock package does not enable embedded MTP.

Coding Harnesses

Use Ollama for normal harness work. It manages the two large models and exposes a stable OpenAI-compatible endpoint. Use direct llama.cpp when a harness needs the measured long-context vision profile or exact control over the quant, MTP, KV cache, and server flags.

Important — One active large model: Do not assign a different large model as a harness’s background or small_model: both models cannot remain resident together on this 24 GB GPU. Model switching would repeatedly unload and reload weights. Keep harness concurrency at one; the direct launcher has one slot, while parallel Ollama requests multiply KV-cache memory.

These launchers and direct-provider settings were checked against the current official Ollama, OpenCode, and Pi documentation on 2026-08-16. OpenCode 1.18.18 and Pi 0.84.2 are installed. After starting a harness, require one tool call and one image smoke test before relying on it.

OpenCode with Ollama

Ollama can install and configure OpenCode, select a local model, and launch the session without changing OpenCode’s persistent configuration:

ollama launch opencode
ollama launch opencode --model qwen3.8-27b-65k
ollama launch opencode --model gemma4-26b-196k

Use qwen3.8-27b-65k for difficult coding or gemma4-26b-196k for speed and longer context. ollama launch opencode --config prepares the integration without opening a session. The launcher passes an inline provider configuration and does not overwrite ~/.config/opencode/opencode.json.

Pi with Ollama

Ollama provides the equivalent supported launcher for Pi. It installs Pi if necessary, configures Ollama as a provider, manages the Ollama web-search package, and opens a session:

ollama launch pi
ollama launch pi --model qwen3.8-27b-65k
ollama launch pi --model gemma4-26b-196k

Use ollama launch pi --config to configure the integration without starting an interactive session. A manual ~/.pi/agent/models.json is only necessary when Pi must connect to a non-Ollama endpoint or override the launcher’s generated metadata.

Harnesses with Direct llama.cpp

For a harness session that bypasses Ollama, start one of the verified vision-mode llama-server commands in Standard Model Profiles. The resulting OpenAI-compatible endpoint is http://127.0.0.1:8080/v1. Run one server at a time; the measured daily vision allocations are 65,536 for Qwen3.8 and 163,840 for Gemma4-26B.

Show the complete OpenCode and Pi llama.cpp configuration

OpenCode provider block:

{
  "$schema": "https://opencode.ai/config.json",
  "provider": {
    "llama-cpp": {
      "npm": "@ai-sdk/openai-compatible",
      "name": "llama.cpp tuned local server",
      "options": { "baseURL": "http://127.0.0.1:8080/v1" },
      "models": {
        "gemma4-26b": {
          "name": "Gemma4 26B — llama.cpp vision 160K",
          "attachment": true,
          "reasoning": true,
          "tool_call": true,
          "limit": { "context": 163840, "output": 8192 },
          "modalities": { "input": ["text", "image"], "output": ["text"] }
        },
        "qwen3.8-27b": {
          "name": "Qwen3.8 27B — llama.cpp vision 64K",
          "attachment": true,
          "reasoning": true,
          "tool_call": true,
          "limit": { "context": 65536, "output": 8192 },
          "modalities": { "input": ["text", "image"], "output": ["text"] }
        }
      }
    }
  }
}

Pi can use the same single-model endpoint by adding this provider beside ollama in models.json:

"llama-local": {
  "baseUrl": "http://127.0.0.1:8080/v1",
  "api": "openai-completions",
  "apiKey": "local",
  "compat": {
    "supportsDeveloperRole": false,
    "supportsReasoningEffort": false
  },
  "models": [
    {
      "id": "gemma4-26b",
      "reasoning": true,
      "input": ["text", "image"],
      "contextWindow": 163840,
      "maxTokens": 8192
    },
    {
      "id": "qwen3.8-27b",
      "reasoning": true,
      "input": ["text", "image"],
      "contextWindow": 65536,
      "maxTokens": 8192
    }
  ]
}

Run the harness with the alias matching the server that is currently active:

opencode -m llama-cpp/qwen3.8-27b
pi --provider llama-local --model qwen3.8-27b

Pi also supports llama.cpp’s multi-model router through /login llama.cpp and /llama. That is a separate workflow: start llama-server without -m, --model, or -hf, point it at a --models-dir, and reproduce the measured per-model settings as llama.cpp presets.

After starting a harness session, use the check for its runtime:

# Ollama
ollama ps

# Direct llama.cpp
curl http://127.0.0.1:8080/health

For a smoke test, require one real tool call; for a vision profile, attach a known test image and verify both a complete answer and full-GPU residency. A successful chat alone does not prove that tool schemas or images reached the model.

Benchmark Toolkit

Run long GPU jobs sequentially in tmux; never run two model servers or benchmarks at the same time. Different tools answer different questions, so their tokens-per-second values should not be mixed into one ranking.

Tool or workloadWhat it measures
ollama-benchNative Ollama prefill, generation, time to first token, load time, and total request time at fixed context allocations.
Native filled-context requestsPractical text and real-image context ceilings, the first CPU-offloaded configuration, and slowdown when attention processes a long history.
GuideLLM API matrixPortable OpenAI-compatible throughput and latency with the same prompts, output limits, concurrency, and image.
llama.cpp SPEED-BenchMTP-off baselines, draft-depth sweeps, accepted drafts, and the best model-specific MTP depth.
Matched backend A/BOllama-bundled versus direct llama-server using the exact same GGUF, precision, flags, prompt, and output work.

The exact installation and benchmark commands appear in the Ollama and llama.cpp sections below. Raw request, server, and GPU-placement logs were retained for validation but are not required to follow the public guide.

Ollama Setup and Benchmarks

Ollama is the convenient model manager and daily runtime. Current Ollama serves GGML models through its bundled upstream llama-server, including embedded MTP support.

Install and Update

Use the official Linux installer:

curl -fsSL https://ollama.com/install.sh | sh
ollama --version

The installed inference runtime used here is:

ollama version 0.32.13

An update alias may be kept in ~/.zshrc:

alias ollama-update='curl -fsSL https://ollama.com/install.sh | sh'

After updating, run ollama --version, pull the models again, and rerun the benchmark rather than assuming backend behavior is unchanged.

Configure Context and MTP

For one native API request, set num_ctx explicitly:

curl http://127.0.0.1:11434/api/generate -d '{
  "model": "qwen3.8:27b",
  "prompt": "Say hi.",
  "options": { "num_ctx": 65536 }
}'

For a service-wide Linux default:

sudo systemctl edit ollama.service
[Service]
Environment="OLLAMA_CONTEXT_LENGTH=65536"
sudo systemctl daemon-reload
sudo systemctl restart ollama

For a persistent per-model profile, export its Modelfile, set PARAMETER num_ctx 65536, and create a new name:

ollama show qwen3.8:27b --modelfile > Modelfile
ollama create qwen3.8-27b-65k -f ./Modelfile

draft_num_predict controls embedded MTP for models that support it. Keep this parameter model-specific and benchmark it; a larger number is not automatically faster.

PARAMETER draft_num_predict 4

Inspect the effective state instead of relying only on the Modelfile:

ollama show qwen3.8:27b --modelfile
ollama ps
journalctl -u ollama.service -n 200 --no-pager | grep 'starting llama-server'

The journal exposes the actual context, parallel slots, batch sizes, projector, Flash Attention mode, MTP flags, and backend command. ollama ps confirms effective context and CPU/GPU placement.

Install ollama-bench

Build the benchmark from the current Ollama source tree:

mkdir -p ~/dev/projects
cd ~/dev/projects
git clone https://github.com/ollama/ollama.git
cd ollama
go build -o ollama-bench ./cmd/bench
./ollama-bench -h

Update an existing checkout with:

cd ~/dev/projects/ollama
git pull --ff-only
go build -o ollama-bench ./cmd/bench

Versions used for the saved results:

ComponentVersion
Ollama inference runtime0.32.13
Ollama source / ollama-bench commite5a81899d014a847a08d47393351908b53d74008
Go modulev0.32.14-0.20260815020320-e5a81899d014
Go1.26.5
Bundled llama-server backendcommit 0b1bad14f, GCC 13.3.1

Pull the Five Models

ollama pull updates an existing tag if its manifest or blobs changed:

ollama pull gemma4:26b
ollama pull gemma4:31b
ollama pull qwen3.6:27b
ollama pull qwen3.6:35b
ollama pull qwen3.8:27b

All five stock packages used Q4_K_M weights. Do not describe a stock-package comparison as a pure runtime comparison with Unsloth UD-Q4_K_XL files.

Native Text Benchmark

The current benchmark was run at both 16,384 and 65,536 context, six timed epochs after one warmup, with a 200-token generation cap:

~/dev/projects/ollama/ollama-bench \
  -model gemma4:26b,gemma4:31b,qwen3.6:27b,qwen3.6:35b,qwen3.8:27b \
  -epochs 6 \
  -num-ctx 65536 \
  | tee ollama-five-models-65k.bench
Model16K generate16K prefill65K generate65K prefill65K TTFT
gemma4:26b183.8 t/s1,901.6 t/s182.7 t/s1,888.5 t/s0.744 s
gemma4:31b43.6 t/s800.6 t/s9.6 t/s143.1 t/s1.336 s
qwen3.6:27b45.4 t/s418.2 t/s45.3 t/s409.8 t/s0.789 s
qwen3.6:35b94.9 t/s564.5 t/s80.2 t/s464.8 t/s0.684 s
qwen3.8:27b91.1 t/s379.2 t/s90.9 t/s371.8 t/s0.739 s

Gemma4-31B crosses a CPU-offload cliff at 65K. This is a capacity result, not an Ollama API failure.

Controlled Ollama API Results

The common API matrix used one request at a time, six requests, a 65K text allocation, a 16K vision allocation, a 256-token throughput cap, and a separate 2,048-token answer-completeness pass. Its short prompts do not constitute a filled-context ceiling test. The table reports GuideLLM output throughput.

ModelText 65KVision 16KVision semantic check
gemma4:26b132.6 t/s114.7 t/sadded a nonexistent Sliding Window node
gemma4:31b9.3 t/s33.9 t/sadded a nonexistent Sliding Window node
qwen3.6:27b44.4 t/s38.1 t/scorrect
qwen3.6:35b81.4 t/s37.4 t/scorrect; non-thinking profile
qwen3.8:27b90.8 t/s56.0 t/scorrect

Gemma image prompts encoded about 308 image tokens while Qwen encoded about 3,434. Vision prefill throughput is therefore not comparable across families; use end-to-end latency and answer correctness.

Daily-Profile Speed at Short and Filled Context

These native-API checks used the selected shared text/vision profiles. Short columns are medians of three 256-token samples; filled requests used 195,584 prompt tokens for Gemma and 64,512 for Qwen.

ModelContextShort textShort visionFilled textFilled vision
gemma4:26b196,608182.7 t/s180.7 t/s97.6 t/s96.7 t/s
qwen3.8:27b65,536123.4 t/s110.0 t/s71.8 t/s72.2 t/s

Configured context alone does not cause the slowdown; attention over an actually long prompt does. Filled latency was about 46–48 seconds for Gemma and 33–37 seconds for Qwen. The Qwen filled-text sample stopped after 22 tokens, while filled vision produced 196, so treat 71.8 t/s as directional; the close vision result supports it.

Build, Configure, and Benchmark llama.cpp

Pull and Build

mkdir -p ~/dev/projects
cd ~/dev/projects
git clone https://github.com/ggml-org/llama.cpp.git
cd llama.cpp

For an existing checkout:

cd ~/dev/projects/llama.cpp
git pull --ff-only

Build for the RTX 4090’s Ada compute capability 8.9:

sudo apt install build-essential cmake libcurl4-openssl-dev libssl-dev

cmake -B build \
  -DGGML_CUDA=ON \
  -DCMAKE_BUILD_TYPE=Release \
  -DCMAKE_CUDA_ARCHITECTURES=89 \
  -DGGML_CUDA_FA_ALL_QUANTS=ON \
  -DLLAMA_OPENSSL=ON

cmake --build build -j8

Build parallelism warning: Use -j8 on this 12-core/24-thread, 32 GB machine. nproc returns 24; that many concurrent CUDA compiler jobs exhausted RAM and made the machine temporarily unresponsive. -j8 was the fastest stable choice measured here.

Tested build:

version: 0.1.0-dev (build 10448, commit ad1de39e0708e3ced9c71bb3c82d93a2c046a73f)
built with GNU 15.2.0 for Linux x86_64

Set the Model Cache Once

Set LLAMA_CACHE before all llama.cpp -hf commands, or put the export in ~/.zshrc once:

export LLAMA_CACHE="${LLAMA_CACHE:-$HOME/dev/ml-data/huggingface/models/llama-cache}"
mkdir -p "$LLAMA_CACHE"
export LLAMA_SERVER="$HOME/dev/projects/llama.cpp/build/bin/llama-server"

The five Unsloth repositories were resolved again before testing; -hf downloads missing or updated blobs into this cache.

Common Server Configuration

The commands below share the same base flags. Per-model sections select the repository, context, MTP depth, reasoning mode, and sampling values.

OptionMeaning
-hf <repo>:UD-Q4_K_XLUse the current Unsloth 4-bit Dynamic GGUF and its matching projector metadata.
--jinjaPin the Jinja chat-template engine used for harness tool calling. The tested server currently defaults to enabled, but the commands make it explicit.
-ngl 99Request full GPU layer offload.
-c <tokens>Allocate the measured mode-specific context.
-fa onEnable Flash Attention.
-np 1Use one slot for reproducible VRAM and latency tests.
-ctk q8_0 -ctv q8_0Use q8 K/V cache to save VRAM relative to f16.
--spec-type draft-mtpEnable embedded multi-token prediction.
--spec-draft-n-max NMaximum speculative draft depth selected by benchmarking.
--no-mmprojText-only: do not load the multimodal projector.
omit --no-mmprojVision: load the matching projector and accept image input.
--reasoning on/offSelect thinking or non-thinking profile explicitly.

Text and vision are separate configurations. A successful projector load is not enough: the ceiling tests sent the fixed image and required a completed response. The projector and image tokens consume VRAM, so vision ceilings are usually lower.

Leave -b and -ub at their defaults for these direct profiles. A 2,048/2,048 Qwen trial improved prefill only about 1.7%, reduced decode speed, and consumed about 1 GiB more VRAM; 4,096 overflowed.

What MTP Does

MTP predicts several future tokens, verifies them against the target path, accepts matching drafts, and rejects the rest. Accepted drafts reduce the number of serial decode steps, so MTP can substantially increase generation speed.

MTP does not increase context length. It adds draft state and GPU work, so a depth that is too high can reduce speed or lower the context ceiling. The useful measurement is accepted drafts plus end-to-end speed, not merely whether the server accepts the flag.

Verify the current build and a live run:

~/dev/projects/llama.cpp/build/bin/llama-server --help | grep spec-type

The server log must show creation of the MTP draft context; completed requests must report non-zero draft generation/acceptance counters.

Request Context Ceilings

These are completed-request ceilings using UD-Q4_K_XL, q8 K/V, the selected MTP profile, and an actual image in vision mode. “Daily” leaves practical headroom; “max pass” is the largest tested successful request.

ModelText dailyText max passFirst text failVision dailyVision max passFirst vision fail
Gemma4-26B196,608262,144native limit reached163,840229,376262,144
Gemma4-31B49,15265,53698,30416,38432,76849,152
Qwen3.6-27B98,304131,072163,84065,53698,304131,072
Qwen3.6-35B65,53665,53698,30416,38449,15265,536
Qwen3.8-27B98,304131,072163,84065,53698,304131,072

Qwen3.6-35B vision uses non-thinking mode with MTP disabled. Its 65K request failed after loading, which is why 16K—not 49K—is the conservative daily profile. None of the five models is rejected; each has a different useful capacity/performance envelope.

MTP Selection with SPEED-Bench

The final text depths were selected with llama.cpp SPEED-Bench at each model’s daily context.

ModelContextMTP offSelected MTPSelected speedAcceptanceSpeedup
Gemma4-26B196,608144.81 t/s6267.44 t/s61.44%1.85×
Gemma4-31B49,15240.86 t/s4110.59 t/s74.50%2.71×
Qwen3.6-27B98,30446.01 t/s4103.63 t/s65.84%2.25×
Qwen3.6-35B65,536168.71 t/s3236.04 t/s70.47%1.40×
Qwen3.8-27B98,30445.45 t/s477.48 t/s39.62%1.70×

These are SPEED-Bench coding-workload numbers, not the same workload as ollama-bench or GuideLLM. Do not compare them directly.

Controlled Direct API Results

This is the direct llama.cpp side of the same GuideLLM API matrix used for Ollama: 65K text, 16K vision, six requests, one slot, and a 256-token cap.

ModelText 65KVision 16KVision semantic check
Gemma4-26B250.2 t/s216.9 t/sadded a nonexistent Sliding Window node
Gemma4-31B103.7 t/s82.9 t/sadded a nonexistent Sliding Window node
Qwen3.6-27B94.5 t/s71.0 t/scorrect
Qwen3.6-35B208.1 t/s55.7 t/sfalse-positive Sliding Window; non-thinking/MTP off
Qwen3.8-27B75.4 t/s67.0 t/scorrect

The separate 2,048-token quality pass caught one truncated Qwen3.6-27B thinking response and one truncated/empty Qwen3.6-35B thinking response. Targeted non-thinking reruns completed without truncation; keep those results labeled rather than silently mixing profiles.

Standard Model Profiles

Each command below runs upstream llama-server directly with the measured profile; no private helper script is required.

Gemma4-26B

FieldTextVision
Sourceunsloth/gemma-4-26B-A4B-it-GGUF:UD-Q4_K_XLsame plus matching projector
Daily context196,608163,840
Maximum completed request262,144229,376
MTP depth66
Reasoningonon
Samplingtemperature 1.0, top-p 0.95, top-k 64same
"$LLAMA_SERVER" \
  -hf unsloth/gemma-4-26B-A4B-it-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 196608 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --no-mmproj --reasoning on \
  --spec-type draft-mtp --spec-draft-n-max 6 \
  --temp 1.0 --top-p 0.95 --top-k 64

For vision, remove --no-mmproj and change the context to -c 163840. SPEED-Bench selected MTP 6 at 267.44 t/s. It has the largest usable context and is the fastest retained long-context profile. The fixed vision smoke test completed but hallucinated a Sliding Window node, so verify diagram details before acting on them.

Gemma4-31B

FieldTextVision
Sourceunsloth/gemma-4-31B-it-GGUF:UD-Q4_K_XLsame plus matching projector
Daily context49,15216,384
Maximum completed request65,53632,768
MTP depth44
Reasoningonon
Samplingtemperature 1.0, top-p 0.95, top-k 64same
"$LLAMA_SERVER" \
  -hf unsloth/gemma-4-31B-it-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 49152 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --no-mmproj --reasoning on \
  --spec-type draft-mtp --spec-draft-n-max 4 \
  --temp 1.0 --top-p 0.95 --top-k 64

For vision, remove --no-mmproj and use -c 16384. SPEED-Bench selected MTP 4 at 110.59 t/s. Direct UD-Q4_K_XL fits at the daily contexts; Ollama’s stock package partially offloads at 65K and falls to 9.6 t/s. Its fixed vision smoke test also hallucinated a Sliding Window node.

Qwen3.6-27B

FieldTextVision
Sourceunsloth/Qwen3.6-27B-MTP-GGUF:UD-Q4_K_XLsame plus matching projector
Daily context98,30465,536
Maximum completed request131,07298,304
MTP depth45
Reasoningonon
Samplingtemperature 1.0, top-p 0.95, top-k 20, min-p 0same
"$LLAMA_SERVER" \
  -hf unsloth/Qwen3.6-27B-MTP-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 98304 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --no-mmproj --reasoning on \
  --spec-type draft-mtp --spec-draft-n-max 4 \
  --temp 1.0 --top-p 0.95 --top-k 20 --min-p 0

For vision, remove --no-mmproj, use -c 65536, and set --spec-draft-n-max 5. SPEED-Bench selected text MTP 4 at 103.63 t/s. The vision sweep selected MTP 5. It read the fixed roadmap correctly in both runtimes. For outputs that spend the whole budget thinking, use an explicitly labeled non-thinking profile.

Qwen3.6-35B A3B

FieldTextVision
Sourceunsloth/Qwen3.6-35B-A3B-MTP-GGUF:UD-Q4_K_XLsame plus matching projector
Daily context65,53616,384
Maximum completed request65,53649,152
MTP depth3off
Reasoningonoff
Samplingtemperature 1.0, top-p 0.95, top-k 20, min-p 0temperature 0.7, top-p 0.8, top-k 20, min-p 0, presence penalty 1.5
"$LLAMA_SERVER" \
  -hf unsloth/Qwen3.6-35B-A3B-MTP-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 65536 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --no-mmproj --reasoning on \
  --spec-type draft-mtp --spec-draft-n-max 3 \
  --temp 1.0 --top-p 0.95 --top-k 20 --min-p 0

The stable vision command is separate because it disables MTP and reasoning:

"$LLAMA_SERVER" \
  -hf unsloth/Qwen3.6-35B-A3B-MTP-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 16384 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --reasoning off \
  --temp 0.7 --top-p 0.8 --top-k 20 --min-p 0 \
  --presence-penalty 1.5

SPEED-Bench selected text MTP 3 at 236.04 t/s. Vision uses this non-thinking, MTP-off profile because the larger configuration failed during real image work despite loading. The direct one-sample image answer added a nonexistent Sliding Window node; the Ollama package answered correctly, so more semantic samples are needed before making a quality claim.

Qwen3.8-27B

FieldTextVision
Sourceunsloth/Qwen3.8-27B-GGUF:UD-Q4_K_XLsame plus matching projector
Daily context98,30465,536
Maximum completed request131,07298,304
MTP depth44
Reasoningonon
Samplingtemperature 1.0, top-p 0.95, top-k 20, min-p 0same
"$LLAMA_SERVER" \
  -hf unsloth/Qwen3.8-27B-GGUF:UD-Q4_K_XL \
  --jinja -ngl 99 -c 98304 -fa on -np 1 \
  -ctk q8_0 -ctv q8_0 --no-mmproj --reasoning on \
  --spec-type draft-mtp --spec-draft-n-max 4 \
  --temp 1.0 --top-p 0.95 --top-k 20 --min-p 0

For vision, remove --no-mmproj and use -c 65536. Unsloth’s Qwen3.8 llama.cpp guide recommends UD-Q4_K_XL and this thinking-mode sampling profile. SPEED-Bench selected MTP 4 at 77.48 t/s. It read the fixed roadmap correctly in both runtimes.

Ollama vs Direct llama.cpp

What the Package API Matrix Does and Does Not Show

The Ollama and direct API matrices use the same prompts, contexts, output limits, concurrency, and image. They are useful end-to-end package comparisons, but not pure runtime comparisons:

  • Ollama used stock Q4_K_M packages, their templates/projectors, f16 KV defaults, and package MTP settings.
  • Direct llama.cpp used Unsloth UD-Q4_K_XL, q8 K/V, measured MTP depths, and explicit text/vision profiles.

Therefore a table where one package is faster cannot attribute the difference to the Ollama wrapper or llama.cpp backend alone.

Matched Backend A/B

To isolate the backend, both binaries were run directly against the exact same Qwen3.8 UD-Q4_K_XL GGUF with identical flags: 65,536 context, full GPU offload, f16 K/V, batch/ubatch 512, one slot, Flash Attention auto, MTP 4 with backend sampling, greedy decoding, EOS ignored, and exactly 256 output tokens for each of six requests. Each backend ran twice at 360 W.

BackendBuildOutput throughputMedian TPOTMedian TTFTMedian requestMTP acceptanceVRAM
Ollama-bundled llama-server0b1bad14f94.79 t/s10.85 ms267.5 ms2.779 s65.8%22,730 MiB
Direct upstream llama-serverbuild 10448, ad1de39e094.76 t/s10.84 ms272.3 ms2.775 s65.8%22,730 MiB

The difference is effectively zero. Current Ollama has no inherent decode-speed penalty or advantage here; its bundled backend and current upstream build perform the same when model, precision, flags, and output work are actually identical.

Which Runtime to Use

Use Ollama by default when you value model pulls, manifests/templates, automatic lifecycle and GPU scheduling, a stable API, simple per-model profiles, and current embedded MTP.

Use direct llama.cpp when you need an exact upstream/fork commit, an arbitrary GGUF without Ollama import/conversion, per-server K/V precision, independent draft-cache control, exact MTP and projector flags, batch/ubatch tuning, tensor/GPU split controls, raw timing and acceptance logs, or llama.cpp tools such as conversion, quantization, and SPEED-Bench.

Ollama’s current source explicitly launches upstream llama-server for GGML models. The practical distinction is management and control, not a guaranteed speed difference.

GPU Power-Limit Verification

The complete tables in this guide remain the 360 W baseline. On 2026-08-16, the same sequential tests were repeated at NVIDIA’s 450 W default with unchanged models, contexts, prompts, concurrency, and selected MTP depths.

ModelSelected llama.cpp profile at 360 WAt 450 WChange
Gemma4-26B267.44 t/s263.41 t/s-1.5%
Gemma4-31B110.59 t/s113.86 t/s+3.0%
Qwen3.6-27B103.63 t/s109.53 t/s+5.7%
Qwen3.6-35B236.04 t/s237.89 t/s+0.8%
Qwen3.8-27B77.48 t/s79.89 t/s+3.1%

The other checks were also mixed rather than a repeatable power-scaling win. Native Ollama generation changed by -4.1% to +3.0% across the five models at 16K and 65K. In the daily profiles, Gemma4-26B changed by -1.9% to +0.4%, while Qwen3.8-27B gained +0.7% to +2.6%. The controlled API matrices contained both regressions and gains.

Keep 360 W as the daily limit: it retained essentially all measured throughput while using less power and thermal headroom. The recommended models, contexts, and MTP depths do not change. After testing, temporary aliases and data were removed, loaded models were stopped, and the 360 W limit was restored and verified. Raw 450 W artifacts were retained locally for reproducibility.

Conclusion

On a 24 GB RTX 4090, model placement and K/V-cache size matter more than the advertised 262K architectural window. Gemma4-26B is the strongest speed and long-context option in this test set, while Qwen3.8-27B is the better quality-oriented dense model for coding, agents, reasoning, and careful image interpretation.

Ollama is the practical default because its current GGML path uses upstream llama-server and matched direct llama.cpp performance when the model and flags were identical. Direct llama.cpp remains valuable for exact GGUF selection, q8 K/V cache, model-specific MTP and projector control, raw metrics, conversion, and quantization. The daily configuration is therefore two Ollama aliases, one active model at a time, explicit context limits, and a 360 W GPU power limit.

Sources
